Draper 12V Lambda Tester and Simulator 24708

Draper 12V Lambda Tester and Simulator 24708

This 12V oxygen sensor tester and simulator is designed for testing both Zirconia and Titania lambda/oxygen sensors. It is suitable for testing 1-4 wire lambda/oxygen sensors, both heated and unheated. The device can simulate rich and lean mixtures to monitor the ECU's response. An LED display shows the crossover signal from the sensor. A wire piercing clamp is included for the positive lead, allowing for quick connection checks and confirming wire identity. Requires a 9V battery (available separately).
Features:

• Tests and simulates Zircona and Titania lambda/oxygen sensors
• Suitable for 1-4 wire sensors - heated and unheated
• LED indicators
• Includes wire piercing clamp
• Requires 9V battery (not supplied)

Product Contents:

• 1 x 12V Lambda Tester and Simulator

Brand: Draper
Stock No: 24708
Part No: ETOT
Warranty: 24 months

Specification:

• Weight: 311g
• Dimensions: 140 x 90 x 35mm
• Fuel type: Petrol and diesel
• Titania: 1V and 5V
• Power supply: 12V vehicle battery
• Zirconia: 1V
• Positive and negative lead length: 2m
• Test probe lead length: 450mm
• Tester battery: 9V (not supplied)

Downloads:

• Product Data Sheet: View Here
• Instruction Manual: View Here
• Declaration of Conformity UK CA: View Here
• Declaration of Conformity CE: View Here
