Sealey 500A Professional Gas/Gasless MIG/MMA/TIG Inverter Welder With Portable Wire Feeder & Water Cooler 415V 3ph

Sealey 500A Professional Gas/Gasless MIG/MMA/TIG Inverter Welder With Portable Wire Feeder & Water Cooler 415V 3ph

MULTI PROCESS INVERTER WELDER - Multi process IGBT inverter Gas/Gasless MIG/TIG/MMA welder suitable for professional fabricators and workshops, as well as mechanics and technicians.

PORTABLE WIRE FEEDER – Fitted with a portable wire feeder allowing access into high or tight spaces that otherwise would not be possible.

WATER COOLED – In-built water cooler allows the torch to remain cooler for longer enhancing efficiency and productivity.

500A MAX OUTPUT - Maximum output of 500A making it ideal for welding a large variety of metals including Steel, Stainless Steel up to 20mm.

2T/4T TRIGGER FUNCTION - 2T/4T torch trigger function allowing greater precision during longer welds.

ACCESSORIES INCLUDED - Supplied with 2m power cable, 2m earth clamp, 3m Euro Mig torch and 2m Electrode holder.

WIRE CAPACITY - Wire capacity of 5-15kg with a diameter of 0.6mm to 1.6mm.

ELECTRODE CAPACITY - Electrode capacity from 1.6mm to 5mm.

3 YEAR GUARANTEE*.

Specification:

• Model No POWERMIG500Wi
• Brand: Sealey
• Nett Weight: 55.7kg
• Welding Current: 50-500A
• Wire Capacity: 5-15kg
• Electrode Capacity: 1.6-5mm
({IF["Duty Cycle MIG: 60% @ 500A 100% @ 388A"!=""]})
• Duty Cycle MIG: 60% @ 500A 100% @ 388A
({ENDIF}) ({IF["Duty Cycle TIG: 60% @ 500A 100% @ 388A"!=""]})
• Duty Cycle TIG: 60% @ 500A 100% @ 388A
({ENDIF}) ({IF["Duty Cycle MMA: 60% @ 500A 100% @ 388A"!=""]})
• Duty Cycle MMA: 60% @ 500A 100% @ 388A
({ENDIF})
• Gas Type: CO2, Argon, CO2/Argon Mix
• Mig Torch (inc): 3m Euro Non-Live Torch
• Supply: 415V 3ph
• Plug Type: Bare Wire
• Power Supply Cable Length: 2m
• Weight: 55.7kg
• IP Rating: IP21S
• Absorbed Power: 19.04kW
• Input Current: 39A (MMA), 38A (MIG)
• Output Voltage: 50A/22V to 500A/40V (MMA), 30A/15.5V to 500A/39V (MIG)
• No Load Voltage: 82V (MMA), 82V (MIG)
• Efficeincy: 0.8
• Specifications for Water Cooler:
• Supply: 230V - 50Hz
• Power: 370W
• Coolant: Distilled Water
• Max Pressure: 3kg/cm²
• Feed Rate: 8L/min
• Tank Capacity: 6L
• Weight: 15kg
• IP Rating: IP21S
• Note* In freezing conditions add antifreeze to the coolant.

Product Guarantee: 3 Years
Catalogue Page: Page 997

Downloadable Files:

• Instructions: View Here
• Parts Diagram: View Here
